    EN10216 1 2 Tube for Pressure Purposes

    European Standard

    Tube for Pressure Purposes

    Standard

    EN10216-1

    EN10216-2

    Application

    It is applied for manufacturing pipeline, vessel, equipment, pipe fittings and steel structure.

    Main Steel Tube Grades

    P195TR1, P195TR2, P235TR1, P235TR2, P265TR1, P265TR2, P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10

    Chemical Composition

    St Steel Grade Chemical Composition%
    C Si Mn P S Cr Mo Ni Al Cu Nb Ti V
    EN10216-1 P195TR1 0.13 0.35 0.70 0.025 0.02 0.30 0.08 0.30 / 0.30 0.01 0.04 0.02
    P195TR2 0.13 0.35 0.70 0.025 0.02 0.30 0.08 0.30 0.02 0.30 0.01 0.04 0.02
    P235TR1 0.16 0.35 1.20 0.025 0.02 0.30 0.08 0.30 / 0.30 0.01 0.04 0.02
    P235TR2 0.16 0.35 1.20 0.025 0.02 0.30 0.08 0.30 0.02 0.30 0.01 0.04 0.02
    P265TR1 0.20 0.40 1.40 0.025 0.02 0.30 0.08 0.30 / 0.30 0.01 0.04 0.02
    P265TR2 0.20 0.40 1.40 0.025 0.02 0.30 0.08 0.30 0.02 0.30 0.01 0.04 0.02
    EN10216-2 P195GH 0.13 0.35 0.70 0.025 0.020 0.30 0.08 0.30 0.02 0.30 0.01 0.04 0.02
    P235GH 0.16 0.35 1.20 0.025 0.020 0.30 0.08 0.30 0.02 0.30 0.01 0.04 0.02
    P265GH 0.20 0.40 1.40 0.025 0.020 0.30 0.08 0.30 0.02 0.30 0.01 0.04 0.02
    13CrMo4-5 0.10-0.17 0.35 0.40-0.70 0.025 0.020 0.70-1.15 0.40-0.60 0.30 0.04 0.30 / / /
    10CrMo9-10 0.08-0.14 0.50 0.30-0.70 0.025 0.020 2.00-2.50 0.90-1.10 0.30 0.04 0.30 / / /



    Mechanical Properties



    Standard Steel Grade Mechanical Properties
    Tensile Strength MPa Yield Strength MPa Elongation % Impact Energy J
    EN10216-1



    		 P195TR1 320-440 ≥195 ≥27 /
    P195TR2 320-440 ≥195 ≥27 ≥40
    P235TR1 360-500 ≥235 ≥25 /
    P235TR2 360-500 ≥235 ≥25 ≥40
    P265TR1 410-570 ≥265 ≥21 /
    P265TR2 410-570 ≥265 ≥21 ≥40
    EN10216-2 P195GH 320-440 ≥195 ≥27 ≥40
    P235GH 360-500 ≥235 ≥25 ≥40
    P265GH 410-570 ≥265 ≥23 ≥40
    13CrMo4-5 440-590 ≥290 ≥22 ≥40
    10CrMo9-10 480-630 ≥280 ≥22 ≥40
